Wharfedale DELTA AX15 15" Active 2Way 750w Loudspeaker

Name: Wharfedale DELTA AX15 15" Active 2Way 750w Loudspeaker
Brand: Wharfedale Pro
SKU: WHA-DELTA-AX15
Price: 1299.00 NZD
Availability: OutOfStock

Capable of producing extraordinary levels of SPL and output, inside every DELTA-AX speaker are high headroom amplifiers exclusively engineered by Wharfedale Pro. The 2 way 12” and 15” models also feature an integrated 2 channel mixer with onboard Qubit DSP insuring smoother and more controlled sonic performance.

$1,299.00

~~$0.00~~ $1,299.00

Availability: Out of stock

SKU#: WHA-DELTA-AX15

Quantity

Description

The updated DELTA-AX series features improved internal electronics. The newly designed power components ensure high performance and extreme reliability. Capable of producing extraordinary levels of SPL and output, inside every DELTA-AX speaker are high headroom amplifiers exclusively engineered by Wharfedale Pro. The 2-way 12” and 15” models also feature an integrated 2 channel mixer with onboard Qubit DSP insuring smoother and more controlled sonic performance.

DELTA-AX is constructed from birch plywood and features dual angle pole mounts to ensure that your sound is aimed directly at the audience, not at the ceiling.

Multiple rigging points and durable construction also make DELTA-AX a great installation solution. Clubs, restaurants and houses of worship around the world already rely on DELTA systems day in, day out.

Key Features:

15" two-way bi-amplified active loudspeaker
Premium Baltic birch construction
750w Continuous power
1500w Peak power

90° x 45° dispersion
2" HF Compression driver
3" LF voice coil
Advanced Internal QuBit DSP

ADVANCED ELECTRONICS:

Dual mic inputs with combi-jack connections for line inputs.
RCA inputs for easy connection to consumer level audio sources.
Hands-on EQ control for Hi and Low frequencies
Balanced Link output to connect to more active loudspeakers.
Hi Pass filter switch to roll off low end when using in a monitor position.

BIRCH PLYWOOD CONSTRUCTION:

DELTA-AX uses premium Baltic birch plywood construction.
Not only does this create a solid and durable cabinet, but also contributes to the overall sound.
DELTA-AX is also covered in our most durable and hard wearing Rhino Rock paint finish. This ensures that a DELTA-AX will always look as good as the day you unboxed it.

This fresh design helps to distinguish between the original DELTA-A models and the updated DELTA-AX models.

CLASS D BI-AMPLIFIED

Inside the DELTA-AX15 are two, highly efficient Class D amplifiers.
Using convection cooling, DELTA-AX models do not use any internal fans. Fans add to product weight, ambient noise and can lead to unreliability. DELTA-AX has no fans!

The two amplifiers are dedicated to each driver. One amp for the HF and one amp for the LF. This perfect matching ensures that the DELTA-AX is highly efficient, converting as much as the laws of physics allow to be converted into audible output power.

Specifications:

Model Name	DELTA-AX15
System type	Active 2-way bi-amplified
Frequency response (+/-3dB)	50Hz - 20kHz
Frequency range (-10dB)	45Hz - 20kHz
Calculated Max SPL @1m	131dB
LF Transducer	15"
Coil size	3"
Impedance	4Ω
HF Transducer	Compression driver
Coil size	2"
Exit size	1.4"
Diaphragm material	Titanium
Impedance	8Ω
Nominal coverage	90° x 45°
Amplifiers
LF Power amp	650w RMS Class D
HF Power amp	100w RMS Class D
Protection	Power switch on / off mute, Thermal, Low line voltage, DC and Short, Clip limiters
Hardware	M10 x 6
	35mm pole socket
	2 x Rubberised 4-way handles
Enclosure	15mm plywood
	Rhino rock paint
Grille material	1.2mm Steel
Unpacked
Height	700mm / 27.56"
Width (front)	446mm / 17.56"
Width (rear)	281.4mm / 11.08"
Depth	406mm / 15.98"
Packed
Height	803mm / 31.6''
Width (front)	638mm / 25.1''
Width (rear)	366mm / 14.4''
Depth	498mm / 19.6''
Weight Net	33.0kg / 72.6lbs
Weight Gross	38.5kg / 84.7lbs

View full details
