Allen & Heath QU-5 38-Input Digital Mixer
Allen & Heath QU‑5D 38‑Input Digital Mixer with Dante
QU‑5D is a professional 38‑input digital mixer with integrated Dante networking, 96kHz XCVI processing, motorised faders, multitrack recording, and flexible control - ideal for live sound, installed audio, and networked workflows
Allen & Heath QU-5D Digital Mixer with Dante
The Allen & Heath QU-5D is a powerful digital mixing console designed for professional live sound, fixed installations, and networked audio environments. Based on the same 96kHz XCVI core as the QU-5, the QU-5D adds an integrated Dante interface for high-performance audio networking and flexible Dante routing, making it ideal for modern production workflows.
Equipped with 38 inputs, motorised faders, and intuitive touchscreen control, the QU-5D delivers outstanding performance and mix precision. Its built-in effects, advanced processing tools, and remote control capability ensure seamless operation across live, broadcast, and installed audio applications.
Compared to the standard QU-5, the QU-5D includes native Dante connectivity, enabling direct integration with Dante-enabled stage boxes, audio networks, and distributed audio systems without additional interface hardware. This makes the QU-5D especially well suited to larger, networked sound systems where audio distribution and routing flexibility are essential.
Key Features
- 38-input digital mixer with 96kHz XCVI processing core
- Integrated Dante audio networking (no external interface required)
- Motorised faders and responsive touchscreen for intuitive control
- Six multi-FX engines with high-quality reverb, delay, and modulation
- SD card and USB-C multitrack recording and playback
- Gain Assistant and Feedback Assistant for fast setup
- DEEP processing support for advanced channel processing options
- SLink expansion port for additional I/O integration
- Remote control via Windows, macOS, iOS, and Android apps
- Flexible routing with 12 mix outputs plus matrix and mono buses
Specifications
- Inputs to Mix: 38 (32 mono/linkable + 3 stereo)
- Mix Outputs: 12 + Main LR
- Matrix: 4 mono/linkable matrix mixes
- Sample Rate: 96kHz
- Processing Core: XCVI
- FX Engines: Six multi-FX engines
- USB Interface: 32x32 USB-C multitrack
- Recording: SD card and USB recording/playback
- Dante Networking: Integrated Dante interface
- Expansion: 128x128 via SLink port
- Control: Touchscreen + motorised faders + remote app support
- Headphone Output: Stereo
With built-in Dante audio networking and robust processing power, the Allen & Heath QU-5D is a flexible mixing solution for demanding live, broadcast, and installation environments.
